CAT C7 HEUI Slow Crank
This diagnostic training video is an example of the videos in the diagnostic series. In this example, the engine is slow cranking and will not start. In this before and after repair example, you will see a scope capture of a bad vs good starter cranking waveform. It is very clear what is wrong in this example. In future videos you will see many examples of how to see events in “space” and how to determine what the issues are.
2004 Dodge Sprinter loss of fuel control
2004 Dodge Sprinter loss of fuel control
In this capture we are looking at the Fuel Rail Pressure, Fuel Control Actuator and Fuel Rail Control. I will show how to look at a capture and sort out the waveform to determine what direction we head. This is a perfect example of what would be posted from a member contribution.
Sample Video 3
CAT C15 Injector Current and Voltage
In this video, I am showing a known good injector current and voltage waveform. You will also see the connection diagram and example so you will understand how to connect the scope to achieve the same results.
Parallax Effect - Perfected
